Large Scale Installation
Fixed Tilt Array
Industrial Application
Onsite Power Generation
Regulatory Advantage
Connection Options
Ground-mounted solar installations enjoy simpler permitting compared to utility-scale projects, as they are typically connected Behind the Meter (BTM) for captive consumption.
Behind the Meter (BTM)
Power generated is consumed onsite by the connected facility. Simpler approvals and faster implementation.
- No power purchase agreement with DISCOM
- Fewer regulatory clearances required
- Direct cost savings on electricity bill
- Faster project timeline (3-6 months)
- Net metering available for excess power
Metered Plant (Grid Export)
For larger projects where generation exceeds consumption. Power exported to grid under PPA or open access.
- Revenue from power sales to grid/third party
- Suitable for MW-scale installations
- Open access or group captive options
- SERC registration required
- Longer approval timeline (6-12 months)
Why Ground-Mounted Has Simpler Approvals
Unlike utility-scale solar farms that require extensive environmental clearances and transmission infrastructure, onsite ground-mounted systems are classified as captive power plants. This means fewer approvals, no land-use change issues (when installed on industrial land), and direct connection to your existing LT/HT infrastructure.
System Overview
Ground-Mounted System Components
Sunlight
Energy Source
Panel Array
DC Power
Inverter
DC → AC
Transformer
Step-Up
Factory/Grid
Power Usage
Solar Panels
High-efficiency bifacial modules for maximum energy harvest from both sides.
Mounting Structure
Galvanized steel or aluminum structures engineered for your site conditions.
Inverter System
Central or string inverters with remote monitoring and grid compliance.
Transformer & Switchgear
Step-up transformer and protection equipment for grid interconnection.
SCADA & Monitoring
Real-time performance monitoring with alerts and analytics.
Balance of System
Cables, earthing, lightning protection, and fencing.
Advantages
Benefits of Ground-Mounted Solar
No Roof Constraints
Install on any available land without structural limitations
Optimal Orientation
True south-facing with ideal tilt angle for maximum yield
Higher Capacity
Larger installations possible compared to rooftop constraints
Easy Maintenance
Ground-level access simplifies cleaning and repairs
Scalable Design
Modular design allows phased implementation
Future Ready
Easy to expand capacity as energy needs grow
Options
Mounting Configurations
Choose the right mounting system based on your budget and generation goals.
Fixed Tilt
Fixed Angle Structure
Most cost-effective option with panels at optimal fixed angle.
- Lowest CapEx
- No moving parts
- Minimal maintenance
- Proven technology
Expected Yield: 4.0-4.5 kWh/kWp/day
Seasonal Tilt
Manual Adjustment
Manual tilt adjustment twice a year for seasonal optimization.
- 5-8% higher yield
- Simple mechanism
- Low additional cost
- Flexible angles
Expected Yield: 4.3-4.8 kWh/kWp/day
Single-Axis Tracker
Automatic Tracking
Panels automatically follow the sun throughout the day.
- 15-25% higher yield
- Maximum generation
- Smart controllers
- Premium returns
Expected Yield: 5.0-5.5 kWh/kWp/day
Land Requirements
| Configuration | Capacity per Acre | Land for 1 MW |
|---|---|---|
| Fixed Tilt | 400 kWp | 2.5 acres |
| Seasonal Tilt | 350-380 kWp | 2.6-2.8 acres |
| Single-Axis Tracker | 300-350 kWp | 2.8-3.3 acres |
How It Works
Our Process
Land Assessment
Topography, soil, access, grid proximity
System Design
Layout optimization, equipment selection
Clearances
Land use, environmental, grid connectivity
Civil Works
Foundation, roads, drainage
Installation
Structure, panels, electrical
Commission
Testing, grid sync, handover
